6. Restoring Division、Non-restoring Division、Booth's Algorithm
#CC-02-006
難
Restoring Division
Non-restoring Division
Booth's Algorithm
📝
☆
Which of the following statements are true?
A
(a) Consider the above ALU design and a multiplication of
00101
2
×
00011
2
00101_2 \times 00011_2
0010
1
2
×
0001
1
2
, the value of Remainder register is
0001111000
2
0001111000_2
000111100
0
2
after three iterations of multiplication is conducted.
B
(b) Consider the same ALU design and now a division of
01101
2
÷
00011
2
01101_2 \div 00011_2
0110
1
2
÷
0001
1
2
using the restoring scheme is conducted. The value of Remainder register is
0000010001
2
0000010001_2
000001000
1
2
after four iterations of division is conducted. Note that the shift operation is performed at the end of each iteration rather than at the beginning.
C
(c) Consider the 5-bit non-restoring division algorithm that performs shift-left operation at the end of each iteration rather than at the beginning. The algorithms require 6 but not 5 iterations to obtain correct quotient.
D
(d) Consider a multiplication of
00101
2
×
01001
2
00101_2 \times 01001_2
0010
1
2
×
0100
1
2
applying the Booth algorithm. This multiplication requires two additions and two subtractions.
